class that implements the More...

#include "onion-routing.h"

Inheritance diagram for ns3::OnionRoutingDummyEncryption:

Collaboration diagram for ns3::OnionRoutingDummyEncryption:

Public Member Functions
	OnionRoutingDummyEncryption (uint16_t sealPadding, const uint16_t protocolNumber)
	Constructor – Setup parameters for the creation of onions and check that `sealPadding` is greter than 4 Bytes. More...

virtual void	DecryptLayer (uint8_t innerLayer, uint8_t onion, uint16_t onionLen, uint8_t pk, uint8_t sk) const

virtual void	EncryptLayer (uint8_t ciphertext, uint8_t message, int len, uint8_t *key) const

void	GenerateNewKey (void)
	Generate a new dummy encryption key of 4Bytes using the uniform random generator. More...

uint8_t *	GetEncryptionKey (void)
	Return the current encryption key. More...

Public Member Functions inherited from ns3::OnionRouting
	OnionRouting ()

	OnionRouting (uint16_t keySize, uint16_t sealPadding, uint16_t addressSize)

	OnionRouting (uint16_t sealPadding, const uint16_t protocolNumber)
	Constructor – Setup parameters for the creation of onions. More...

virtual	~OnionRouting ()

void	AddressToStream (uint8_t *ip)

void	AddressToStream (uint8_t *ip)
	Output an ip address to a stream variable, used to LOG the onion message. More...

int	BuildOnion (uint8_t cipher, uint8_t route, uint16_t routeLen, uint8_t keys, uint8_t content, uint16_t contentLen)

void	BuildOnion (uint8_t cipher, uint8_t route, uint8_t *keys, uint16_t routeLen)
	Manage construction of the onion ONION_NO_CONTENT. More...

void	BuildOnion (uint8_t cipher, uint8_t route, uint8_t keys, uint16_t routeLen, uint8_t endContent, uint16_t endContentLen)
	Manage construction of the onion ONION_ENDCONTENT. More...

void	BuildOnion (uint8_t cipher, uint8_t route, uint8_t keys, uint8_t *layerContent, uint16_t layerContentLen, uint16_t routeLen)
	Manage construction of the onion ONION_LAYERCONTENT. More...

void	BuildOnion (uint8_t cipher, uint8_t route, uint8_t keys, uint8_t layerContent, uint16_t layerContentLen, uint16_t routeLen, uint8_t endContent, uint16_t endContentLen)
	Manage construction of the onion ONION_LAYERCONTENT_ENDCONTENT. More...

int	CreateOnion (uint8_t cipher, uint8_t route, uint16_t index, uint16_t routeLen, uint8_t keys, uint8_t content, uint16_t contentLen)

void	CreateOnion (uint8_t cipher, uint8_t route, uint8_t keys, uint16_t index, uint16_t routeLen, uint8_t layerContent, uint16_t layerContentLen, uint8_t endContent, uint16_t endContentLen)
	Constructs the onion message *. More...

enum OnionErrno	GetErrno (void)
	Return the last error code of the OnionErrno enum. More...

uint16_t	OnionLength (uint16_t routeLen, uint16_t contentLen)

uint16_t	OnionLength (uint16_t routeLen, uint16_t layerContentLen, uint16_t endContentLen)
	Compute the length in bytes of the onion message at given parameters. More...

orLayer *	PeelOnion (uint8_t onion, uint16_t onionLen, uint8_t pk, uint8_t *sk)

orLayer *	PeelOnion (uint8_t onion, uint16_t onionLen, uint8_t publicKey, uint8_t *secretKey)
	Decipher the outer layer of the onion and return details. More...

Static Public Member Functions
static TypeId	GetTypeId (void)
	Register this type. More...

Static Public Member Functions inherited from ns3::OnionRouting
static TypeId	GetTypeId (void)

static TypeId	GetTypeId (void)
	Register this type. More...

Public Attributes
uint8_t	m_encryptionkey [4]
	the current encryption key More...

Public Attributes inherited from ns3::OnionRouting
uint16_t	m_addressSize
	size in bytes of the used address type (4-Ipv4, 16-Ipv6) More...

enum OnionErrno	m_errno
	error status while using the onion class More...

uint16_t	m_keySize

std::stringstream	m_onionStream
	stringstream used to LOG onion construction More...

uint16_t	m_sealPadding
	size increase of the ciphertext in bytes, intorduced by the encryption method More...

Additional Inherited Members
Public Types inherited from ns3::OnionRouting
enum	OnionErrno { ERROR_NOTERROR, ERROR_PROT_NUMBER, ERROR_ROUTE_TO_SHORT, ERROR_ENCRYPTION, ERROR_DECRYPTION }
	Enumeration of the possible errors using the class onion-routing. More...

Detailed Description

class that implements the

Definition at line 339 of file onion-routing.h.

Constructor & Destructor Documentation

◆ OnionRoutingDummyEncryption()

ns3::OnionRoutingDummyEncryption::OnionRoutingDummyEncryption	(	uint16_t	sealPadding,
		const uint16_t	protocolNumber
	)

Constructor – Setup parameters for the creation of onions and check that sealPadding is greter than 4 Bytes.

Parameters

[in]	sealPadding	size increase of the ciphertext in bytes, intorduced by the simulated encryption method
[in]	protocolNumber	value detailing the utilized IP protocol: IPv4–Ipv4L3Protocol::PROT_NUMBER, IPv6–Ipv6L3Protocol::PROT_NUMBER

Definition at line 303 of file onion-routing.cc.

Member Function Documentation

◆ DecryptLayer()

void ns3::OnionRoutingDummyEncryption::DecryptLayer	(	uint8_t *	innerLayer,
		uint8_t *	onion,
		uint16_t	onionLen,
		uint8_t *	pk,
		uint8_t *	sk
	)		const

virtual

Implements ns3::OnionRouting.

Definition at line 349 of file onion-routing.cc.

References ns3::OnionRouting::ERROR_DECRYPTION, ns3::OnionRouting::m_errno, and ns3::OnionRouting::m_sealPadding.

◆ EncryptLayer()

void ns3::OnionRoutingDummyEncryption::EncryptLayer	(	uint8_t *	ciphertext,
		uint8_t *	message,
		int	len,
		uint8_t *	key
	)		const

virtual

Implements ns3::OnionRouting.

Definition at line 338 of file onion-routing.cc.

References ns3::OnionRouting::m_sealPadding.

◆ GenerateNewKey()

void ns3::OnionRoutingDummyEncryption::GenerateNewKey ( void )

Generate a new dummy encryption key of 4Bytes using the uniform random generator.

Definition at line 323 of file onion-routing.cc.

References m_encryptionkey.

◆ GetEncryptionKey()

uint8_t * ns3::OnionRoutingDummyEncryption::GetEncryptionKey ( void )

Return the current encryption key.

Returns: the encryption key in the form of a 4 bytes uint8_t array

Definition at line 331 of file onion-routing.cc.

References m_encryptionkey.

◆ GetTypeId()

TypeId ns3::OnionRoutingDummyEncryption::GetTypeId ( void )

static

Register this type.

Returns: The object TypeId.

Definition at line 313 of file onion-routing.cc.

Member Data Documentation

◆ m_encryptionkey

uint8_t ns3::OnionRoutingDummyEncryption::m_encryptionkey[4]

the current encryption key

Definition at line 381 of file onion-routing.h.

Referenced by GenerateNewKey(), and GetEncryptionKey().

The documentation for this class was generated from the following files:

src/onion-routing/model/onion-routing.h
src/onion-routing/model/onion-routing.cc
